- 1 to 16: connecting analog Z terminals.
4.2.1.1.3 UAI Board
RJ45 pin 1 2 3 4 5 6 7 8
1 to 16 (UAI) L1 L2
- 1 to 16: connection of digital terminals or DECT 4070 IO/EO base stations.
4.2.1.1.4 UAI-1 Board
RJ45 pin 1 2 3 4 5 6 7 8
1 L1 L2 0V 48V
2 to 16 L1 L2
- 1 : connection of an EPS48 external power supply + connection of digital terminals or
DECT 4070 IO/EO base stations.
- 2 to 16: connection of digital terminals or DECT 4070 IO/EO base stations.
4.2.1.1.5 BRA Board
RJ45 pin 1 2 3 4 5 6 7 8
1 to 8 TX+ RX+ RX- TX-
- 1 to 8: connection of T0/DLT0 basic access.
4.2.1.1.6 PRA Board
RJ45 pin 1 2 3 4 5 6 7 8
NETW outputs RX+ RX- TX+ TX-
PBX outputs TX+ TX- RX+ RX-
- NETW: connection to the public network (TNL).
- PBX: use in private network with TX and RX twisted pairs.
4.2.1.1.7 LANX and LANX-1 Board
RJ45 pin 1 2 3 4 5 6 7 8
Ports 1 to 15 RX+ RX- TX+ TX-
Up-Link TX+ TX- RX+ RX-
- Ports 1 to 15: internal ports.
- Up-Link: LAN connection.
