Displaying SIP Connection Current Status
As of R9.0, this feature allows the display of SIP connection status.
To display SIP connection status:
1. In OMC, go to Users/Base stations List > Details.
2. Read the SIP connection status (under the terminal's physical status).
The following table lists the different displayed status.
Displayed Status Meaning
Set not connected SIP phone disconnected from network / No
SIP registration request from the phone
SIP registration KO SIP registration request from SIP Phone rejec-
ted by Alcatel-Lucent OmniPCX Office Com-
munication Server
Set unregistered SIP phone unregistered from Alcatel-Lucent
OmniPCX Office Communication Server
SIP registration OK SIP phone connected and successfully re-
gistered to Alcatel-Lucent OmniPCX Office
Communication Server
4.4.2.1.3 Video Call parameters
The Alcatel-Lucent OmniPCX Management Console is used to enable the video call support
for the 8082 My IC Phone sets. Once configured it is possible to make:
- Basic P2P video calls between 8082 My IC Phone (VHE-2) and any SIP phone with video
support.
- Basic video calls from 8082 My IC Phone (VHE-2) over a SIP trunk
The configuration for video is carried out in two steps:
1. Generic SIP phone parameters for video calls are verified and modified if necessary, see
Generic video parameters
2. Each set is enabled, see Enabling video support for a 8082 My IC Phone set
Generic video parameters
The parameters in the table are generic (common) to all 8082 My IC Phone sets. They are
accessed from:
OMC -> Subscribers Misc -> Generic Parameters for SIP Phones -> Video Call
parameters
Video Camera Country Frequency: defines the vertical scan frequency which is needed to
avoid flickering of video. This is same as the mains power frequency of the country. Default
value for this parameter is kept based on the target type (country) of the OmniPCX Office.
Chapter
4
&'(
4-46
