16
1
2
4
3
1. Service
With this function, you can see
certain values of the boiler on
the screen. The values are
updated once a second
2. Resetting the system
With this function the panel can
be reset to factory setting. After
resetting, the panel is set as
follows: the boiler in Off mode,
electrical operation 1kw, LPG
heating in On mode and indoor
temperature 22°C.Other func-
tions are disconnected.
10. Service and Resetting the system
10:1 Service menus
Activated
Functions
Heater temp:
Sanitary temp:
Fan rotation:
Current:
Current:
Overheat:
Window switch:
Extern start:
RPM
A
deact/act
deact/act
deact/act
Soft Rev.
Heater:
Panel:
Cl Version:
3. Translator
This function is used to enable
an external main panel to ope-
rate the boiler. If a main panel
is connected to the Alde panel,
it is activated with the On but-
ton, otherwise it must always
be set at Off. Factory setting
is Off.
4. OK
To leave the tool menu, press
OK or Menu.
