Layout/Scope of delivery HTW250/240P
10
AFTER SALES SUPPORT
aldi.service.uk@scheppach.com
00800 4003 4003
MODEL: HTW250/240P PRODUCT CODE: 64055 xx/2017
ter into the fuel tank opening. Make sure that the lter is seated in the lower corner
of the fuel tank (12). If necessary, use a long screwdriver to move the lter to its
correct position, taking care not to damage it in the process.
8. Securely ret the fuel tank cap (10).
Changing the cutting blade (Fig. 10)
1. Hold the spindle in place with the allen key (26). Use the open end wrench (24) to
remove the ange nut, by turning in an anti-clockwise direction.
2. Remove the ange nut, and cutting blade (8).
NOTE: Ensure that all parts are clean of any dirt or grass prior to tting.
3. Fit the new cutting blade (8) over the inner ange.
4. Fit the ange nut and tighten rmly using the open end wrench (23) supplied, in a
clockwise direction. Use the allen key (26) to stop the spindle rotating.
IX. TECHNICAL DATA
Engine 2-Stroke, 25.4 cm
3
Engine power 0.75 kW
Engine idling speed 3000±200 min
-1
Engine maximum speed 9000 min
-1
Cutting blade length 224 mm
Cutting depth 35 mm
Tank capacity 0.6 l
Mixing ratio (fuel / two-stroke oil) 40:1
Subject to technical changes!
AUS
Maintenance, cleaning and servicing/Technical data LE2500P
22
AFTER SALES SUPPORT
support@scheppach.com.au
1300 855 831
MODEL: LE2500P PRODUCT CODE: 61758 09/2018
