Attachment HBS20
Adjusting the bottom guide pins (46) (Fig.7+8)
• Disassemble saw table (7).
• Undo screw for bottom retainer (43).
• Move bottom retainer (47), bottom guide pins (46), until the front edge of the bottom
guide pins (46) is approx. 1 mm behind the tooth base of the saw band.
• Retighten screw for bottom retainer (43).
• ATTENTION! The saw band will be unusable if the teeth touch the guide pins with
the saw band running.
• Undo Allen screws for bottom guide pins (45).
• Slide the two bottom guide pins (46) sufciently far in the direction of the saw band that
the distance between the bottom guide pins (46) and saw band (21) is max. 0.5 mm. (Saw
band must not jam)
• Retighten Allen screws for bottom guide pins (45).
• Turn the bottom saw band roller (8) a few times in a clockwise direction.
• Check the setting of the bottom guide pins (46) again and adjust if necessary.
• If necessary, adjust the bottom support bearing (42).
Adjusting the top saw band guide (5) (Fig. 9)
• Undo locking handle for saw band guide (23).
• Turn the adjustment handle for the saw band guide (22) to lower the top saw band
guide (5) as closely as possible (distance approx. 2-3 mm) over the material to
be cut.
• Retighten locking handle for saw band guide (23).
• Check the setting before every cutting process and adjust if necessary.
Adjusting the saw table (7) to 90° (Fig.10+11)
• Set the top saw band guide (5) fully upwards.
• Undo locking handle for saw band table (20) and wing nut (31).
• Place the angle bracket between the saw band (21) and saw table (7). Angle brack-
et not included in the scope of supply.
• Tilt the saw table (7) by turning, until the angle to the saw band (21) is precisely
90°. If the saw table is already on the screw (49) and a 90° angle cannot be set,
undo the nut (50) and shorten the screw (49) by turning in a clockwise direction.
• Retighten the locking handle for saw band guide (20) and wing nut (31).
• Also undo the nut (50).
• Adjust the screw (49) sufciently that the saw table touches the underside.
• Retighten the nut (50) to x the screw (49) in position.
