24V Lithium-ion Cordless Drill with Hammer Action
AFTER SALES SUPPORT
e-mail: info.aldi@positecgroup.com
1300 889 028
MODEL: №. CDI224 • 09/2020 • 63524
(toll free)
22
All drill/driving operations
• Mark o the centre of the hole using a centre punch or nail
(Do not use centre punch in Masonry applications).
• Don’t force the drill/driver, let it work at its own pace
• Keep the drill/driver bit sharp.
• Reduce pressure, as the drill/driver is about to break through the item
being drill/drivered.
LED work light
When the unit is switched on, the LED work light (12) also comes on to
ensure better vision and to make working in dark areas more safe.
The working light goes out when the On/O trigger (8) is released.
CAUTION! LED is laser class 1!
Do not look directly into the laser as this may result in damage to the eyes.
Chuck replacement
The chucks of reversible drill/drivers are always xed by a screw with a left-
hand thread. The screw, which is located in the centre of the chuck, must
be removed before the chuck can be removed. To remove the screw, turn it
in a clockwise direction. The chuck can now be removed by unscrewing it
anti-clockwise. If you have trouble removing the chuck take the drill/driver
to your nearest authorised service centre for chuck replacement.
CAUTION. Always ensure that the drill/driver is switched o and the battery
pack is removed before making any adjustments.
Side Belt Clip
The belt clip (5) is used to assist to clip the tool to your waist belt while
working.
Carry strap
A carry strap (17) is included on the drill and is already tted for convenience.
Cleaning
Clean the case only with a damp cloth. DO NOT use solvents when cleaning
plastic parts. Plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use a clean cloth to
remove dirt, dust, oil, grease etc, then dry well.
All drill / driving operations
