Alecto IVM-180 - Camera Overview

5
10
1
3
4
5
6
8
2
9
7
3 CAMERA OVERVIEW
1. Lens
2. Sensor for IR LEDS
3. Microphone
4. Antenna
5. Loudspeaker
6. Setting switch link/pairing
7. Power supply input
8. LED indicator
9. Reset button
10. Temperature sensor
LED Indicator:
Red - no connection
Flashing green - ready as own Wi-Fi access point
Green - connected to network
Sensor for IR LEDS:
The infrared LEDs light up the area around the lens in the dark.
The illumination of the infrared LEDs only give light visible to the camera.
.
