9Alere Cholestech LDX
®
System User Manual
The Test Cassette
The test cassette has two parts: the main body and the reaction
bar. The main body contains a sample well where the blood
sample is dispensed, and a brown magnetic stripe. The magnetic
stripe contains the test names, instructions to the analyzer for
running the tests on the cassette, and calibration information for
converting the color reading to test concentration.
Main Body
Sample Well
Magnetic Stripe
Reaction Bar
