Chapter 9: The A6 Modulation Matrix
196 ANDROMEDA A6 REFERENCE MANUAL
MOD BUTTONS WITH MULTIPLE DESTINATIONS (continued)
OSC 1 (cont.) OSC2->LIN FM modulates the amount of linear FM modulation
from Oscillator 2
OSC2->EXP FM modulates the amount of exponential FM
modulation from Oscillator 2
EXT->PWIDTH modulates the amount of pulse width modulation
from the Noise/External module
EXT->LIN FM modulates the amount of linear FM modulation
from the Noise/External module
EXT->EXP FM modulates the amount of exponential FM
modulation from the Noise/External module
LIN FM
EXP FM
MOD
(OSC 2 FM)
Pulse Width
modulates the level of OSC 2 modulating OSC 1’s
frequency in two different ways
modulates the level of OSC 2 modulating OSC 1’s
square wave pulse width
OSC 2 MOD 1, 2 and 3 FREQUENCY modulates the frequency of the oscillator
SQR WAVE LVL modulates the level of the square wave output
from the oscillator
PULSE WIDTH modulates the pulse width of the oscillator
EXT->PWIDTH modulates the amount of pulse width modulation
from the Noise/External module
EXT->EXP FM modulates the amount of exponential FM
modulation from the Noise/External module
FREQUENCY modulates the frequency of the filterFILTER 1 and
FILTER 2
MOD 1, 2 and 3
RESONANCE modulates the resonance of the filter
DELAY,
ATTACK, DECAY
1, DECAY 2,
RELEASE 1,
RELEASE 2
modulates the time of these filter segmentsMOD 1, 2 and 3
ENVELOPE
LEVEL, SUSTAIN
LEVEL
modulates the level of the entire envelope, or the
sustain segment
ENV 1
ENV 2 and
ENV 3
TRIGGER TRIGGER and
RETRIGGER
triggers the envelope in response to the modulation
source
VOICE MIX MOD MAIN OUT PAN
AUX OUT PAN
modulates the pan of the Main or Aux stereo
outputs
