Chapter 4: Andromeda A6 Overview
ANDROMEDA A6 REFERENCE MANUAL 95
A6 FUNCTION LIST
We continue with a list of A6 functions. Each function will be explained in the section
following this list. Detailed descriptions will be covered throughout this manual.
Memory
256 factory Programs (in Flash memory)
128 user-programmable Programs
128 factory Mixes (in Flash memory)
128 user-programmable Mixes
Tone Sources
32 true analog Voltage-Controlled Oscillators (2 per voice) w/ hard and soft sync
and sub-oscillation
3 external audio inputs (-10dB):
one input to Voice 15 Filters, one input to Voice 16 Filters and one Mono
Input to All filters
1 full-spectrum analog Noise Generator, capable of producing White, Pink and
Red noise
Tone Modifiers
32 true analog Voltage-Controlled Filters w/ resonance (2 per voice)
Filter 1: dynamic 2-pole low-pass, high-pass, band-pass and notch
Filter 2: dynamic 4-pole low-pass
16 Ring Modulators (1 per Voice)
Modulation Sources (per Voice)
3 Low Frequency Oscillators
1 Sample-and-Hold generator
3 multi-stage, multi-mode Envelopes
1 multi-stage Tracking Generator
Audio Mixing
3 in-line signal level controls: Pre-Filter Mix, Post-Filter Mix and Voice Mix to
final out through true analog Voltage-Controlled Amplifiers
Controllers
5-octave (C-to-C) velocity, aftertouch and pressure-sensitive semi-weighted
keyboard
Modes: full, layer and split w/ polyphonic, monophonic and unison voicings
assignable Pitch and Modulation wheels
assignable, splittable Ribbon controller
rear-panel Volume and Sustain pedal inputs
rear-panel Oscillator and Filter control voltage inputs
Real-time Arpeggiator
16-event, programmable Step Sequencer, 1 per Program
Master Clock control
