SECTION 2
BACKPANEL
MIDI IN
The MIDI IN jack is used to receive MIDI data from a sequencer,
sampler, synthesizer, or effects processor for storage on diskette.
MIDI OUT
The MIDI OUT jack is used to send MIDI file data to a sequencer,
synthesizer, or sampler. This jack can also be selected to function
as a MIDI THRU jack so that it echo's an exact copy of what is being
received by the MIDI IN jack.
POWER
The POWER jack is a 4 pin DIN jack which connects to the outboard
9 VAC power transformer.
