5
Features
Top Panel
1. Power Button: Press this button to turn the drum module on. Press and hold it for 2
seconds to turn the drum module off.
2. Display: This screen shows information relevant to the drum module's current function
and operation.
3. Volume Knob: Turn this knob to adjust the volume of the Main Outputs and Phones
Output.
4. – / + : Press either of these buttons to decrease or increase the value shown in the
display.
5. Click Button: Press this button to turn the metronome ("click") on or off. See Using the
Metronome (Click) for more information.
6. Start/Stop Button: Press this button to start or stop playback of a pattern. See Playing
Along with Patterns for more information.
7. Pattern Button: Press this button to enter Pattern Mode. Press both this button and the
Tempo Button simultaneously to use the Built-In Drum Coach. See Playing Along with
Patterns and Using the Built-In Drum Coach for more information.
8. Tempo: Press this button to enter Tempo Mode and use the – / + buttons to adjust the
tempo. Press both this button and the Pattern Button simultaneously to use the Built-In
Drum Coach. See Using the Metronome (Click) and Using the Built-In Drum Coach
for more information.
9. 1-5/Variation Buttons: Press any one of these buttons to enter Kit Mode and select a
Kit. When using the Built-In Drum Coach, you can use these buttons to select an
exercise. See Using Kits and Using the Built-In Drum Coach for more information.
