3Installation
Studytheinstructionscarefullyandpayspecialattentiontothewarnings!AlwayschecktheAgitatorbeforeoperation.The
Agitatorisonlydesignedtooperateaccordingtodatagiveninchapter2.3Intendeduse,6.2Mountingangleforsidemounted
AgitatortypeALSand6.3MountingangleforbottommountedAgitatortypeALB.Checktherotationdirectionbeforeoperation.
Step Step
Step
8 8
8
Ensurethatdrain(I)ispointingdownwards.
Forgearswithventscrew,ensuretheventispointingupwardsandtherubberplug(III)isremoved(seechapter8.1Driveunit
instructionsandmountinginstructionsinStep1onpage20.
Step Step
Step
9 9
9
(OnlyforAgitatorswithbearingframe)
EnsurethatthePreVentvalveisrefittedinthebearingframe.
Step Step
Step
10 10
10
Ensurethattherotationdirectionisaccordingtonameplate,beforestartingtheAgitator.
Step Step
Step
11 11
11
Iffrequencyconverterdriveisused,itmustbeensuredNOTtooperatecontinuouslywithin+/-20%ofcriticaloscillation
speed(seechapter2.3Intendeduseand6Technicaldata).
Step Step
Step
12 12
12
AlfaLavalrecommendasoftstarterorafrequencyconverterfortheAgitatortoreducetheloadontankandAgitator.For
operationinstructionsfromsupplierssee8Appendix.
Therampupandrampdowntimeshouldbeabout2-5seconds.
