Alfa Laval CPM-2 User Manual

3Installation
Studytheinstructionscarefullyandpayspecialattentiontothewarnings!
Theitemsrefertothepartslistandservicekitssection.
ThevalvecanbefittedwithaBoostertoallowforaproductpressurehigherthanavailableairpressure.
Step Step
Step
6 6
6
1.Fitcover(8)onBoosterhousing(1).
2.Fitandtightenclamp(9).
3.ThevalveandtheBoosterarenowreadyforoperation.
Step Step
Step
7 7
7
Compr Compr
Compr
essed essed
essed
air: air:
air:
Anairpressurecompensatingregulatingvalvemustbeusedandshouldbeinstalledwithmin.clearancetotheBooster/
CPM-2valve.
Thepressureregulatingvalve(PR)andthepressuregauge(PG)areoptionalextras.
AlfaLavalrecommendsusingtheairpressureregulatingvalvefromAlfaLaval.
ø164
CPMI-2:232.4mm
CPMO-2:272.3mm
3.5Recyclinginformation
• •
•
Unpacking Unpacking
Unpacking
-Packingmaterialconsistsofwood,plastics,cardboardboxesandinsomecasesmetalstraps
-Woodandcardboardboxescanbereused,recycledorusedforenergyrecovery
-Plasticsshouldberecycledorburntatalicensedwasteincinerationplant
-Metalstrapsshouldbesentformaterialrecycling
• •
•
Maintenance Maintenance
Maintenance
-Duringmaintenanceoilandwearpartsinthemachinearereplaced
-Allmetalpartsshouldbesentformaterialrecycling
-Wornoutordefectiveelectronicpartsshouldbesenttoalicensedhandlerformaterialrecycling
13
