5Maintenance
Studytheinstructionscarefully.
Theitemsrefertothepartslistandservicekitssection.
Handlescrapcorrectly.
CPMI-2:Constant-PressureModulatingInlet.CPMO-2:Constant-PressureModulatingOutlet.
Step Step
Step
5 5
5
Removelowerinnerring(11)andlowerdiaphragm(14).
Step Step
Step
6 6
6
Removesectors(12).
Step Step
Step
7 7
7
Removeouterring(13),upperinnerring(11)andupperdiaphragm
(10).
Step Step
Step
8 8
8
Removeguide(9)fromcover(7).
Step Step
Step
9 9
9
RemoveO-ring(8)fromguide(9).
22
