3 Installation
This instruction manual is part of the delivery. Study the instructions carefully.
The larger pumps sizes are very heavy.
Alfa Laval therefore recommends the use of a lifting crane when handling the pump.
3.1 Unpacking/delivery
Step 1
Always use a lifting crane when handling the pump (see technical
data).
CAUTION
Alfa Laval cannot be held responsible for incorrect unpacking.
Check the delivery for:
1. Complete pump.
2. Delivery note.
3. Motor instructions.
Step 2
Remove possible packing materials from the inlet and the outlet.
Avoid damaging the inlet and the outlet.
Avoid damaging the connections for flushing liquid, if supplied.
TD 252-004
Remove
packing
materials!
Caution!
Step 3
Inspect the pump for visible transportation damage.
Inspect!
TD 252-004
Step 4
Always remove the shroud, if fitted, before lifting the pump.
Remove the shroud before lifting!
TD 252-005
7
