English Installation
4 Plate Heat Exchanger
eng
eng
Lifting
M15, TL10, T20, TS20
MX25, M30, MA30
TL35
Warning!
Never lift by the connections or the studs
around them. Straps should be used when
lifting. Place straps according to picture.
β
β
β
45
°
β
β
β >45
°
