Alfa Laval MX25 - Page 5

Installation English
Plate Heat Exchanger 5
eng
eng
Raising
Place two timber beams on the floor.
Lift the heat exchanger off pallet using e.g.
straps.
Place the heat exchanger on the timber
beams.
Place straps around one bolt on each side.
Lift the heat exchanger off the timber
beams.
Lower the heat exchanger to horizontal
position and place it on the floor.
1
2
3
4
5
6
