8 Parts list and service kits
It is important to observe the technical data during installation, operation and maintenance.
Inform the personnel about the technical data.
NO = Normally open. NC = Normally closed.
Parts list
Pos. Qty Denomination
Actuator, complete
11
Cap
2 
1
O-ring
3
1
Cylinder
4  1
Lock wire
5 
1
O-ring
61Piston
7 
1
O-ring
8 1 Bonnet
9
1
Plug
10 1
Spring packet
14 ♦ 1Lipseal
15
2
Clamp complete
16 1 Valve body
17 ♦
2
Seal ring
18
1
Valve body
20
1
Plug
20b
1
Stem
20c ♦ 1Plugseal
20d
1
Middle piece
20e ♦
1
Plug seal
20f
1
Washer
20g ♦
1
O-ring
20h
1
Screw
21  1
Guide ring
22  1
Guide ring
23 1 Top pin
24  1
O-ring
25  1
Guide ring
26 1 Air fitting
27 
1
Guide ring
Service kits
Denomination NC NO
Service kit for Actuator

Service kit EPDM ..............................................
9611-92-0296 9611-92-0296
Service kits
Denomination DN 125 DN 150
Service kit for Product wetted parts
♦
Service kit EPDM ..............................................
9611-92-0358 9611-92-0358
♦
Service kit NBR ................................................
9611-92-0359 9611-92-0359
♦
Service kit FPM ................................................
9611-92-0360 9611-92-0360
Parts marked with
♦ areincludedintheservicekits.
Recommended spare parts: Service kits.
900-093/2
31
