Alfa Laval SRU series User Manual

6 Technical data
6.1.4 Pump Data Table
Displacement Suction & Discharge
Sanitary
Enlarged
Differential
Pressure
Model
litres/rev
Imp gal/
100 rev
US gal/
100 rev
mm
inch.
mm
inch. bar
psi
Max.
Speed
rev/min
Max.
Capacity at
1000 rpm
m3/hr
SRU1/005/LD or H
0.053 1.17 1.40 25 1.0
--
8 115 1000 3.18
SRU1/008/LD or H
0.085 1.87 2.25 25 1.0 40 1.5
575
1000 5.10
SRU2/013/LS or HS 0.128 2.82 3.38 25 1.0 40
1.5
10
145
1000 7.68
SRU2/013/LD or HD 0.128 2.82 3.38 25 1.0 40
1.5 15
215 1000 7.68
SRU2/018/LS or HS
0.181 3.98 4.78 40 1.5 50 2.0 7 100 1000 10.86
SRU2/018/LD or HD
0.181 3.98 4.78 40 1.5 50 2.0 10 145 1000 10.86
SRU3/027/LS or HS
0.266 5.85 7.03 40 1.5 50 2.0 10 145 1000 15.96
SRU3/027/LD or HD
0.266 5.85 7.03 40 1.5 50 2.0 15 215 1000 15.96
SRU3/038/LS or HS 0.384 8.45 10.14 50 2.0 65 2.5
7
100 1000 23.04
SRU3/038/LD or HD 0.384 8.45 10.14 50 2.0 65 2.5 10
145
1000 23.04
SRU4/055/LS or HS
0.554 12.19 14.64 50 2.0 65 2.5 10 145 1000 33.24
SRU4/055/LD or HD
0.554 12.19 14.64 50 2.0 65 2.5 20 290 1000 33.24
SRU4/079/LS or HS
0.790 17.38 20.87 65 2.5 80 3.0
7
100 1000 47.40
SRU4/079/LD or HD
0.790 17.38 20.87 65 2.5 80 3.0 15 215 1000 47.40
SRU5/116/LS or HS 1.160 25.52 30.64 65 2.5 80 3.0 10
145
600 41.76
SRU5/116/LD or HD 1.160 25.52 30.64 65 2.5 80 3.0 20 290 600 41.76
SRU5/168/LS or HS
1.680 36.95 44.38 80 3.0 100 4.0 7 100 600 60.48
SRU5/168/LD or HD
1.680 36.95 44.38 80 3.0 100 4.0 15 215 600 60.48
SRU6/260/LS or HS
2.600 57.19 68.68 100 4.0 100 4.0 10 145 500 78.00
SRU6/260/LD or HD
2.600 57.19 68.68 100 4.0 100 4.0 20 290 500 78.00
SRU6/353/LS or HS 3.530 77.65 93.25 100 4.0 150 6.0
7
10 500 105.90
SRU6/353/LD or HD 3.530 77.65 93.25 100 4.0 150 6.0
15
215 500 105.90
Please Note:
Maximum differential pressure capability of the pump does not apply to the pressure rating of the mechanical seals which is
20 bar, and the selected port connection as stated below:
SMS – 10 bar (all sizes)
RJT – 10 bar (all sizes)
DIN11851 – 40 bar (25-40mm), 25 bar (50-100mm), 16 bar (150mm)
IDF/ISS – 16 bar (25-50mm), 10 bar (65-150mm) providing provision for support ring is to be made.
Tri-clamp (BS4825) – Pressure rating is dictated by the clamp band used.
Refer to clamp band supplier.
For size 150mm on SRU6/0353 pumps, only DIN11851, SRJT or Tri-clamp connections are available.
Note:
ATEX applications: Differential pressure, Max. speed and Max. capacity are not applicable for ATEX applications.
39
