Alfa Laval SRU series User Manual

7 Parts list
Parts list
Pos. Qty Denomination
11
Gearcase
22Dowel
3
4
Stud, rotorcase retention
4 4 Nut, rotorcase retention
4a 4
Washer, rotorcase retention
51
Cover, gearcase
66
Screw, gearcase cover
7
1 Lip seal, drive end
82
Shim
8a 2
Shim retainer
8b 4
Screw, shim retainer
9
1
Rotorcase
10
4
Stud, rotorcase/cover retention
11 1
O-Ring, cover - plain
12
1
Cover, rotorcase
13 4 Dome nut, rotorcase cover
14 2 Retainer, seal
15
6
Screw, seal retainer
16 2 Lip seal, gland end
17 2 Rotor
18 2
O-Ring, rotor sealing shaft end
20 2
O-Ring, rotor sealing nut end
22 2 Nut, rotor retention
23 1 Key
24 1
Shaft, drive
25
1
Shaft, auxiliary
26 2 Bearing, rear
27 1
Spacer, shaft abutment
30 2 Nut, bearing
31 2 Bearing, front
32 2
Spacer, bearing
36 2 Timing gear
38 2 Torque locking element
39 2
Clamp plate
40 12
Screw, clamp plate
45
2Drainplug
46 1
Sight glass
47 1 Filler plug
48 2 Plug
49
4
Blanking plug
50 2
Gland guard
51 4
Screw, gland guard
52
4
Washer, gland guard screw
53
4
Washer, gland guard
54 1
Foot, vertical port
56
1
Foot, horizontal port
58 2 Bolt, Foot
45
