Alfa Laval SRU series User Manual

7 Parts list
Parts list
Pos. Qty Denomination
11
Gearcase
22Dowel
3
4
Stud, rotorcase retention
4 4 Nut, rotorcase retention
4a 4
Washer, rotorcase retention
51
Cover, gearcase
66
Screw, gearcase cover
7
1 Lip seal, drive end
82
Shim
8a 2
Shim retainer
8b 4
Screw, shim retainer
9
1
Rotorcase
10 8
Stud, rotorcase/cover retention
11 1
O-Ring, cover
12 1
Cover, rotorcase
13 8 Dome nut, rotorcase cover
14
2 Retainer, seal
15 6
Screw, seal retainer
16 2 Lip seal, gland end
17
2 Rotor
18 2
O-Ring, rotor sealing shaft end
20 2
O-Ring, rotor sealing nut end
22 2 Nut, rotor retention
23
1
Key
24
1
Shaft, drive
25 1
Shaft, auxiliary
26
4
Bearing, rear
27
1
Spacer, shaft abutment
28 2
Spacer, bearing drive end
29 2
Spacer, bearing gland end
30 2 Nut, bearing rear
31 4 Bearing, front
34 2 Nut, bearing front
36 2 Timing gear
37 2 Torque locking assembly
45
7
Drain plug
46
1
Sight glass
47 1
Filler plug
50 2
Gland guard
51 4
Screw, gland guard
52
4
Washer, gland guard
53 4 Washer, gland guard
54 1
Foot, vertical port
56
1
Foot, horizontal port
58 4 Bolt, foot
53
