Alfa Laval ThinkTop v.3.0 User Manual

9 Parts list and Service Kits
The drawings show ThinkTop AS-Interface v.2.1 (31 n odes) & v.3.0 (62 nodes) 29.5 - 31.6 VDC.
The items refer to the parts lists in the following sections
9.1 Drawings fo r ThinkTop AS-Interface
TD 800-149
ø137 mm
H
W
171.6 mm
18
18
TD 800-263
Note! This is the basic design.
Valve Type
HW
Unique SSV NC
225 250
SMP-SC/-BC/-TO
225 250
Unique Mixproof 225 250
MH 225 250
SBV
225 250
Unique SSV NO
225 320
LKLA-T 225 300
6b
6a
TD 800-171
1
2
3
33
