Alfa Laval ThinkTop v.3.0 User Manual

9 Parts list and Service Kits
The drawings show ThinkTop AS-Interface v.2.1 (31 nodes) & v.3.0 (62 nodes) 29.5 - 31.6 VDC Series 700 valves.
The items refer to the parts lists in the following sections
9.3 Drawings for ThinkTop AS-Interface for Series 700
TD 800-205
ø137 mm
H
W
171.6 mm
TD 800-269
Note! This is the basic design.
Valve Type
HW
Unique SSV NC
225 250
SMP-SC/-BC/-TO
225 250
Unique Mixproof 225 250
MH 225 250
SBV
225 250
Unique SSV NO
225 320
LKLA-T 225 300
6a
6b
TD 800-262
1
3
2
37
