Alfa Laval ThinkTop v.3.0 User Manual

9 Parts list and Service Kits
The drawings show ThinkTop AS-Interface v.2.1 (31 n odes) & v.3.0 (62 nodes) 29.5 - 31.6 VDC.
The items refer to the parts lists in the following sections
Parts list
Pos. Qty Denomination
11
Shell complete
31
Screw
41
Washer
5
1
Sensor board
6a 1-2
Solenoid valve
6b
1
Solenoid valve
7
3PTscrew
8
1
Base
(Pos.9,12,13,14 included)
9
1
Special X-ring, grey
10
1
Air fitting
17 1
O-ring
18 2 Allen screw
19
1
Special X-ring
20
1
Indication pin
23
1
2 m ASI drop cable
Service kits
a
Solenoid valve 3/2, 24 VDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9611-99-3324
a
Solenoid valve 5/2, 24 VDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9611-99-3327
a
Indication pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9612-5623-01
a
Special indication pin, SRC-LS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9612-6370-01
a
Special indication pin, Unique SSV-LS . . . . . . . . . . . . . . . . . . . . . . . .
9613-1581-01
a
Special indication pin, Unique SSV High Pressure . . . . . . . . . . . . .
9613-1581-01
a
Air fitting, Ø6 mm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9611-99-3405
a
Air fitting, 1/4" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9611-99-3433
a
Gore vent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9611-99-4722
a
X-ring, pos. 9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9613-4564-01
a
X-ring, pos. 16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9612-9994-01
a
X-ring, pos. 19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9612-5696-01
a
Sensor board AS-Interface 29.5-31.6 VDC (period -0902 . . . . .
9612-5627-03
a
Sensor board AS-Interface v.2.1 (31 nodes) (period 0902- ) . .
9613-4434-02
a
Sensor board AS-Interface v.3.0 (62 nodes) (period 0902- ) . .
9613-4434-03
TD 900-389/7
35
