Alfa Laval ThinkTop v.3.0 User Manual

9 Parts list and Service Kits
The drawings show ThinkTop AS-Interface v.2.1 (31 nodes) & v.3.0 (62 nodes) 29.5 - 31.6 VDC Series 700 valves.
The items refer to the parts lists in the following sections
Parts list
Pos. Qty Denomination
(Pos.9,12,13,14 included)
11
Shell complete
3
1
Screw
41
Washer
5
1
Sensor board
6a 1-2
Solenoid valve
6b 1
Solenoid valve
7
3PTscrew
81Base
9
1
Special X-ring, grey
10
1
Air fitting
11
2Blow-offvalve
12
1
Thread plug
13 1
Cable gland
14 1
Gore vent High airflow
15 1 Adapter complete
16 1
Special X-ring, black
17 1
O-ring
18 4
Screw
19
1
Retainer
20
1
O-ring
21
1
O-ring
22
1
Indicator pin
23 1 Nut
25 1
2 m ASI drop cable
Service kits
a
Solenoid valve 3/2, 24 VDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9611-99-3324
a
Solenoid valve 5/2, 24 VDC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9611-99-3327
a
Indication pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9612-6357-02
a
Air fitting, 1/4" . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9611-99-3433
a
Gore vent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9611-99-4722
a
X-ring, pos. 9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9613-4564-01
a
X-ring, pos. 16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9612-9994-01
a
Sensor board AS-Interface 29.5-31.6 VDC (period -0902 . . . . .
9612-5627-03
a
Sensor board AS-Interface v.2.1 (31 nodes) (period 0902- ) . .
9613-4434-02
a
Sensor board AS-Interface v.3.0 (62 nodes) (period 0902- ) . .
9613-4434-03
TD 900-393/5
