5.2 Manual setup
1
Perform mechanical installation as shown in
section 4.1
2
Move valve to the initial position
The initial position is the position to be
associated with the valve De-energized
signal. If open / closed feedback is desired,
the initial position should be the valves closed
position. For NO valves DE-EN is not the
closed position.
3
Perform electrical installation as shown in
section 4.2
4
Observe green flashing
5
Move the valve to the opposite of its initial
position
6
Observe white light [Energized position
feedback]
7
Move the valve back to its initial position
8
Observe green light [De-energized position
feedback]
Setup is now complete
9
Run an IO-test to verify that the system
returns the desired feedback
NOTE
Setup can be cancelled at any step before
step 8 by removing power from the ThinkTop.
200008387-1-EN-GB16
