P.28
TROUBLESHOOTING
SPECIFICATIONS
12 xtures of up to 16 channels.
30 banks of 8 scenes each for a total 240 scenes.
6 chased each up to 240 scenes.
8 faders adjust the DMX output level from O to 255.
2 faders control chase speed and fade time.
Built in Microphone.
Blackout
Power Input DC9-12V / 300mA
DMX Output
Connecteur XLR 3 broches de type femelle
Size 19"x 5.25 x 3" (inch)
Colors don't respond when faders are moved.
∙ Make sure address is correct .
∙ If the XRL cable is more than 30 meters, check if it is terminated properly.
Mirrors don't respond when faders are moved.
∙ Make sure address is correct. Make sure speed is adjusted, if available, for faster movement.
∙ If the XRL cable is more than 30 meters, check if it is terminated properly.
Scenes don't run after record them.
∙ Make sure to press ADD button before pressing SCENE button.
∙ Be sure you are in the correct Bank that has scenes recorded.
Scenes don't run correctly as recorded them.
∙ Made sure all xtures were recorded.
∙ Make sure you are in the correct bank that has scenes recorded.
∙ If the XRL cable is more than 30 meters, check if it is terminated properly.
Chase don't run after record them.
∙ Make sure to press ADD button after pressing SCENE button. LED should blink after pressing ADD button.
∙ Be sure you are in the correct chase that has steps recorded.
∙ If in Auto Mode, did you adjust speed after selecting Auto?
∙ Is Fade time to long for speed selected?
∙ If the XRL cable is more than 30 meters, check if it is terminated properly.
