OPERATION INSTRUCTIONS
INTRODUCTION
This device lets you program 12 scanners with 16 DMX channels, 30 banks with 8 program-
mable scenes and 6 chases of 240 programmed scenes using 8 faders and other control buttons.
To customize your effects, you can assign or invert DMX channels.
Two or more devices can communicate with each other and receive or send data.
DMX 512 ADDRESSING
Select the address wanted by adding the total or Dip switches on. Dip Switch no .10 is not used with DMX
but normally to select some functions, i.e. Master /Slave, Sound activation, etc.
Each of the 12 xtures is assigned 16 channels. The Dip switches are set as per the chart below :
When addressing your xtures, follow the starting address in this instruction
not the addressing found in your xture user manual.
SCANNERS CHANNELS DIP SWITCHES ON
1 1-16 0 or 1 based on scanner
2 17-32 1 - 5
3
33-48 1 - 6
4 49-64 1 - 5 - 6
5 65-80 1 - 7
6 81-96 1 - 5 - 7
7 97-112 1 - 6 - 7
8
113-128 1 - 5 - 6 - 7
9 129-144 1 - 8
10 145-160 1 - 5 - 8
11
161-176 1 - 6 - 8
12
177-192 1 - 5 - 6 - 8
QUICKQUICK
TIPS
