DMX PROTOCOL
CH1
DIMMER 0-255 Dimmer 0-100%
CH2
STROBE
0-3 Not used
4-251
Strobe from
Slow to Fast
252-255 Not used
CH3
PAN 0-255 PAN
CH4
PAN Précis 0-255 PAN Fine
CH5
TILT 0-255 TILT
CH6
TILT Précis 0-255 TILT Fine
CH7
PAN-TILT vitesse 0-255 PAN-TILT Speed
CH8
ROUE COULEUR
0-4 White
5-9 Color 1
10-14 Color 2
15-19 Color 3
20-24 Color 4
25-29 Color 5
30-34 Color 6
35-39 Color 7
40-44 White + Color 1
45-49 Color 1 + Color 2
50-54 Color 2 + Color 3
55-59 Color 3 + Color 4
60-64 Color 4 + Color 5
65-69 Color 5 + Color 6
70-74 Color 6 + Color 7
75-79 Color 7 + White
80-255
Rotate from
Slow to Fast
CH9
ROUE GOBOS FIXE
0-9 White
10-19 Gobo 1
20-29 Gobo 2
30-39 Gobo 3
40-49 Gobo 4
50-59 Gobo 5
60-69 Gobo 6
70-79 Gobo 7
80-129
ROTATION
Counterclockwise
Slow to Fast
130-134 White
135-220
ROTATION clockwise
Slow to Fast
221-225
GOBO 1 SHAKE
Slow to Fast
226-230
GOBO 2 SHAKE
Slow to Fast
231 - 235
GOBO 3 SHAKE
Slow to Fast
236-240
GOBO 4 SHAKE
Slow to Fast
241- 245
GOBO 5 SHAKE
Slow to Fast
CH9
ROUE GOBOS FIXE
246-250
GOBO 6 SHAKE
Slow to Fast
251-255
GOBO 7 SHAKE
Slow to Fast
CH10
ROUE GOBOS
ROTATIFS
0-9 White
10-19 Gobo 1
20-29 Gobo 2
30-39 Gobo 3
40-49 Gobo 4
50-59 Gobo 5
60-69 Gobo 6
70-129
ROTATION
Counterclockwise
Slow to Fast
130-134 White
135-225
ROTATION
clockwise
Slow to Fast
226-230
GOBO 1 SHAKE
Slow to Fast
231-235
GOBO 2 SHAKE
Slow to Fast
236-260
GOBO 3 SHAKE
Slow to Fast
241-245
GOBO 4 SHAKE
Slow to Fast
246-250
GOBO 5 SHAKE
Slow to Fast
251-255
GOBO 6 SHAKE
Slow to Fast
CH11
ROTATION GOBOS 0-63 POSITION
64-127
ROTATION
clockwise
Slow to Fast
128-190
ROTATION
clockwise
Fast to Slow
191-192 Stop Rotation
193-255
ROTATION
Counterclockwise
Slow to Fast
PRISME 0-9 No Prism
10-14 Prism Inserted
15-255
Rotation Prisme
Lent > Rapide
FOCUS
0-255 Focus 0-100%
RESET 0-249 Complete RESET
250-255 Not used
