7
6
8
175
"
346
13
5
8
6.2
158
8.3
210
9.5
241
5.8
148
NOTES:
ELECTRICAL: 120-277 VAC, 1PH, 50/60Hz1.
CONFORMS TO HAZARDOUS AREA RATING:2.
ATEX/IECEx Ex db IIA T3 Gb1.
UL CLASS I, DIV 1, GROUP D T32.
ENCLOSURE : TYPE 4, HORIZONTAL OR VERTICAL MOUNT3.
RELIEF VALVE SET: 250 PSIG [17,24 BAR]4.
MAWP: 250 PSIG AT 300°F [17,24 BAR AT 149°C]5.
MDMT: -20°F AT 250 PSIG [17,24 BAR AT -29°C]
WEIGHT: 50 LB [23 KG]6.
DIMENSIONS SHOWN IN INCHES [MM]7.
FRONT VIEW
END VIEW
END VIEW
X 12 GA [3.3mm²]
POWER WIRE
24" [610] LG.
W/PIPE AWAY OPTION
PRESSURE RELIEF VALVE
3/4"-14 MNPT
ELECTRICAL CONNECTION
POINT
PROJECTION
Tel: (206) 789-5410 Fax: (206) 789-5414
Drawn By:
Checked By:
Approved By:
Date:
Scale:
Job #Part #
Title:
Dwg. #Size:
Sht. No.: Rev.:
TOLER AN C E S
151 S. Michigan St., Seattle, Washington. USA 98108
SPECIFIED
B
UNLESS OTHERWISE
1/4"DRAWING
AAS
ASDI STD
1of 1
N/A
0903-6001 B
1/29/2018
1:8 AND NOTED
SCALE
WITH ANSI/ASME Y14.5-2009
INTERPRET THIS DRAWING IN ACCORDANCE
DO NOT
0.030
ALL RIGHTS RESERVED.© COPYRIGHT ALGAS-SDI
.XX
MANNER DETRIMENTAL TO ALGAS-SDI'S INTERESTS.
AND SHALL NOT BE REPRODUCED OR USED IN ANY
THIS DRAWING IS PROPRIETARY AND CONFIDENTIAL
0.10
.XXX 0.010
.X
ANGLE 1
FRACTIONS
THIRD ANGLE
ZIMMER 1PH, EQUIPMENT DRAWING
TOP VIEW
VAPOR OUTLET
1/2"-14 FNPT
2.7
69
684
26.9
3.3
83
LIQUID INLET
1/2"-14 FNPT
BOTTOM VIEW
3.3
83
3.3
84
5.6
141
4.2
108
VAPOR OUTLET
1/2"-14 FNPT
2.7
69
