6
7
8
"
175
54
1
8
"
1375
8.3
210
6.2
158
VAPOR OUTLET
3/4"-14 FNPT
2.7
69
241
9.5
5.8
148
PROJECTION
Tel: (206) 789-5410 Fax: (206) 789-5414
Drawn By:
Checked By:
Approved By:
Date:
Scale:
Job #Part #
Title:
Dwg. #Size:
Sht. No.: Rev.:
TOLERANCES
151 S. Michigan St., Seattle, Washington. USA 98108
SPECIFIED
B
UNLESS OTHERWISE
1/4"DRAWING
AAS
ASDI STD
1of 1
N/A
0903-6002 B
1/31/2018
1:16 AND NOTED
SCALE
WITH ANSI/ASME Y14.5-2009
DN
INTERPRET THIS DRAWING IN ACCORDANCE
DO NOT
0.030
ALL RIGHTS RESERVED.© COPYRIGHT ALGAS-SDI
.XX
MANNER DETRIMENTAL TO ALGAS-SDI'S INTERESTS.
AND SHALL NOT BE REPRODUCED OR USED IN ANY
THIS DRAWING IS PROPRIETARY AND CONFIDENTIAL
0.10
.XXX 0.010
.X
ANGLE 1
FRACTIONS
THIRD ANGLE
ZIMMER 3PH, EQUIPMENT DRAWING
NOTES:
ELECTRICAL: 1PH 110-277VAC, 3PH 4 WIRE WYE 240-480 VAC, 50/60Hz1.
CONFORMS TO HAZARDOUS AREA RATING:2.
IECEx/ATEX Ex db IIA T3 Gb1.
UL: CLASS I, DIV 1, GROUP D T32.
ENCLOSURE: TYPE 4, HORIZONTAL OR VERTICAL MOUNT3.
RELIEF VALVE SET: 250 PSIG [17,24 BAR]4.
MAWP: 250PSIG AT 300°F [17,24 BARG AT 149°C] 5.
MDMT: -20°F [-29°C] AT 250 PSIG [17,24 BAR]
WEIGHT: 170 LB [77 KG]6.
DIMENSIONS SHOWN IN INCHES [MM]7.
END VIEW
END VIEW
PRESSURE RELIEF VALVE
W/PIPE AWAY OPTION
3/4"-14 MNPT
ELECTRICAL
CONNECTION
POINT
FRONT VIEW
24" [610] LG X
12 GA [3.3mm²]
POWER WIRES
VAPOR OUTLET
3/4"-14 FNPT
TOP VIEW
3.3
83
2.7
69
67.4
1712
LIQUID INLET
3/4"-14 FNPT
BOTTOM VIEW
4.2
108
5.6
141
84
3.3
3.3
83
