AlgoLaser DIY KIT MK2 - Page 18

Fit the X-Axis into the left Y-Axis Frame.
Fit the X-Axis into the right Y-Axis Frame.
Assemble the X-Axis Component
02/ 11
B
Rear Frame
C
Left Y-Axis Frame
D
Right Y-Axis Frame
X-Axis Frame
Make Y-Axis pass through
the middle of the X-Axis gear
B
Rear Frame
12
