AlgoLaser DIY KIT MK2 - Page 23

05/ 11
Assemble the Limit Switch
Screw Placement
Place the screws
into the two
frontmost holes
80% completed, keep up the good work! We will be able to see the complete DIY KIT MK2 soon!
M2.5X9 screw
M2.5X9 screw
M2.5X9 Screw * 4
Limit Switch Mounting Plate
Limit Switch
