Alienware 13 R2 User Manual

Removing the display back-
cover
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before working inside your computer.
After working inside your computer, follow the instructions
in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Prerequisites
NOTE: This chapter is applicable only if you have purchased a laptop with
non-touchscreen display.
1 Remove the base panel.
2 Follow the procedure from step 1 to step 5 in “Removing the solid-state
drive”.
3 Follow the procedure from step 1 to step 8 in “Removing the palm rest”.
4 Remove the display assembly.
5 Remove the display bezel.
6 Remove the display panel.
7 Remove the display hinges.
8 Remove the camera.
105

Alienware 13 R2 Specifications

General

Tcase	- °C
Bus type	OPI
Stepping	D1
Tjunction	100 °C
FSB Parity	No
Processor cache	4 MB
Processor cores	2
Processor model	i7-6500U
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6500 Mobile series
Processor socket	LGA 1356 (Socket B2)
Processor threads	4
Processor codename	Skylake
Configurable TDP-up	25 W
Number of QPI links	-
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.6 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR2EZ
Processor ARK ID	88194
Processor package size	42 X 24 mm
CPU configuration (max)	1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
CUDA cores	640
On-board graphics card ID	1916
Discrete graphics card model	NVIDIA® GeForce® GTX 960M
On-board graphics card model	Intel® HD Graphics 520
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Maximum internal memory (64-bit)	16 GB
Intel® Virtualization Technology (Intel® VT)	VT-x, VT-d
Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Market positioning	Gaming
Memory slots	2x SO-DIMM
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Memory layout (slots x size)	2 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Total storage capacity	256 GB
Pixel pitch	0.115 x 0.115 mm
Display surface	Matt
Display diagonal	13.3 \
Display brightness	400 cd/m²
Display resolution	3200 x 1800 pixels
Native aspect ratio	16:9
Audio system	Creative Sound Blaster X-Fi MB3
Speaker power	2 W
Speakers manufacturer	Klipsch
Video capturing speed	30 fps
Front camera resolution	1920 x 1080 pixels
Front camera resolution (numeric)	2.1 MP
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Pointing device	Touchpad
Battery voltage	14.8 V
Battery capacity	51 Wh
Battery life (max)	10.5 h
Battery recharge time	4 h
AC adapter power	130 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	6.7 A
AC adapter output voltage	19.5 V
Cable lock slot type	Noble
Operating shock	110 G
Operating altitude	-15.2 - 3048 m
Non-operating shock	160 G
Operating vibration	0.66 G
Non-operating altitude	-15.2 - 10668 m
Non-operating vibration	1.3 G
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	235 mm
Width	328 mm
Weight	2058 g
Height (rear)	27.9 mm
Height (front)	26.34 mm
