Alienware 13 R2

Replacing the touch pad
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before working inside your computer.
After working inside your computer, follow the instructions
in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the touchpad with the screw holes on the palm-
rest assembly.
2 Replace the screws that secure the touchpad to the palm-rest assembly.
3 Slide the touchpad cable into the touchpad connector and press down the
latch to secure the cable.
Post-requisites
1 Follow the procedure from step 5 to step 9 in “Replacing the palm rest”.
2 Follow the procedure from step 3 to step 7 in “Replacing the solid-state
drive”.
3 Replace the base panel.
42
