Alienware 13 R2

Replacing the display back-
cover
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before working inside your computer.
After working inside your computer, follow the instructions
in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/regulatory_compliance.
Procedure
NOTE: This chapter is applicable only if you have purchased a laptop with
non-touchscreen display.
1 Place the display back-cover on a flat surface.
2 Adhere the display-board cable and the camera cable to the display back-
cover.
Post-requisites
1 Replace the camera.
2 Replace the display hinges.
3 Replace the display panel.
4 Replace the display bezel.
5 Replace the display assembly.
6 Follow the procedure from step 5 to step 9 in “Replacing the palm rest”.
7 Follow the procedure from step 3 to step 7 in “Replacing the solid-state
drive”.
8 Replace the base panel.
