About Your Monitor | 11
Monitor Specifications
Flat Panel Specifications
Model AW2518HF
Screen type Active matrix - TFT LCD
Panel technology TN
Aspect Ratio 16:9
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
622.3 mm (24.5 inches)
543.74 mm (21.41 inches)
302.62 mm (11.91 inches)
164545.63 mm
2
(255.05 inch
2
)
Pixel pitch 0.2832 mm x 0.2802 mm
Pixel per inch (PPI) 90
Viewing angle 160° (vertical) typical
170° (horizontal) typical
Luminance output 400 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Faceplate coating Anti-Glare with 3H hardness
Backlight LED edgelight system
Response time 1 ms gray-to-gray
Color depth 16.7 million colors
Color gamut 72%* (CIE1931)
Built-in devices • USB 3.0 super-speed hub (with 1 x USB 3.0
up
stream port)
• 4 x USB 3.0 downstream ports (including 1
po
rt which supports power-charging)
