Alienware m15 R7

Display assembly
Removing the display assembly
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the
rear-I/O cover.
About this task
The following image(s) indicate the location of the display assembly and provides a visual representation of the removal procedure.
44
