Note: The horizontal angle is important when you hang the product from the ceiling. Excessive
inclination may bring about abnormal rotation of the camera lens.
Fixed on a wall (Fig. 1)
Fixed on a ceiling (Fig. 2)
Audio/Video Output
Plug the AV converter in the audio/video output.
The yellow RCA female plug is for video output.
The white RCA female plug is for audio output.
LAN Socket
Insert your LAN cable in the LAN socket.
8
