ALLEN & HEATH 14:4:2 MixWizard WZ3 - ECN 1072: 2-Track Output Level Change; Details of Change

WZ
3
14:4:2 2-track output level change
ECN No: 1072
Assembly No(s): 003-213
Date: September 27th 2004
Reason: To enhance the performance of the 2-track output
Details of change:
Assy 003-213, PCB AG5398
Change R36 & R37 from (AC0369) RES SMD 1K 1% 0805
to (AC4101) RES SMD 68R 5% 0805
Circuit up-issued to iss.2.2.
This change was applied to issue 2 PCBs from serial no. 066551.
ECN 1072
