WZ
3
14:4:2 Front / Base panel up-issue
ECN No: 1067
Assembly No(s): 003-205
Date: August 31
st
2004
Reason: Visual enhancement: bases appear bent
Details of change:
Assy 003-205, WZ
3
14:4:2
Move the holes in the front of the base panel outwards and add one in the
middle to aid straightness of base panels.
Up Issue AA5524 14:4:2 FRONT PANEL FROM 5 TO 6
Up Issue AA5458 W3 BASE PANEL FROM 3 TO 4
Along with the moving of 2 holes and addition of 1 hole, all the base holes are
now countersunk; therefore a screw change is required:
Change 7 x AB0072 SCREW M3X6 PAN TORX BK
to 7 x AB5836 SCREW M3X6 CSK POZI BK U/H PIP
