ALLEN & HEATH GL2400 User Manual

F0!! ! ! ! ! ! !!!!!!!!!!!!!!!!!!!!!!!!!!!! ! GL2400!1234!5#&63!
3
1+3 = 12V
LAMP
XLR male socket XLR female socket
PIN 2 = HOT
Sleeve=ground
Ring=return
Tip=send
UNBALANCED
INSERT
INPUT / OUTPUT
13 GRP 4+ 12 AUX 1+ 11 AUX 2+ 10 AUX 3+ 9 AUX 4+ 8 AUX 5+ 7 AUX 6+ 6 PFL+ 5 AFL+ 4 nc 3 PFL DC 2 AFL DC 1 0V (PAFL)
GRP 4- 32
AUX 1- 31
AUX 2- 30
AUX 3- 29
AUX 4- 28
AUX 5- 27
AUX 6- 26
PFL- 25
AFL- 24
nc 23
nc 22
nc 21
nc 20
14 GRP 3+ 15 GRP 2+ 16 GRP 1+ 17 R+ 18 L+ 19 0V (CHS)
GRP 3- 33 GRP 2- 34 GRP 1- 35
R- 36
L- 37
SYS-LINK II OUTPUT OPTION
1=ground
2=hot +
3=cold -
BALANCED
Female XLR plug
UNBALANCED
link Ring to Sleeve
Sleeve=ground
Ring=cold -
Tip=hot +
UNBALANCED
BALANCED
Sleeve=ground
Ring=RIGHT
Tip=LEFT
HEADPHONES
INPUTOUTPUT
12
3
XLR male plug
2=hot +
1=ground
3=cold -
21
3
UNBALANCED
BALANCED
4 = 0V
1
SYS-LINK V2 OPTION

ALLEN & HEATH GL2400 Specifications

General

Auxiliary Sends	6
Groups	4
Type	Analog
Stereo Inputs	2
Channels	24
Power Supply	Internal
Fader Type	100mm
Weight	Varies with channel count; 16ch: 17kg
Mic/Line Inputs	24
