8
GL3000 USER G UIDE ISS.1
GL3000-816 width 771mm ................. weight 21kg
GL3000-824 width 1026mm ............... weight 29kg
GL3000-832 width 1281mm ............... weight 37kg
GL3000-840 width 1536mm ............... weight 45kg
GL3000-8M width 255mm ................. weight 8kg
RPS9 POWER SUPPLY
weight 5kg
GL3000 CONSOLE
Stereo inputs fitted to
right of master section
16, 24, 32 and 40 channel models.
GL3000-816 16 mono, 8 groups, 8 aux, 2 stereo returns, 2 matrix, L,R, Mono sum
GL3000-824S 20 mono, 4 stereo, 8 groups, 8 aux, 2 stereo returns, 2 matrix, L,R, Mono sum
GL3000-832S 28 mono, 4 stereo, 8 groups, 8 aux, 2 stereo returns, 2 matrix, L,R, Mono sum
GL3000-840S 36 mono, 4 stereo, 8 groups, 8 aux, 2 stereo returns, 2 matrix, L,R, Mono sum
With separate RPS9 rack mount power supply unit.
Can work with RPSD dual supply combiner/monitor.
8 channel bolt-on expander to extend any size console to a maximum 40 channels.
GL3000-8M 8 mono inputs
GL3000-4SM 4 mono, 4 stereo mic/line inputs
Optional VU meterpod for all lighting conditions. Moving coil VU ballistics.
GL3000-M24 24way VU meterpod Monitors groups (aux) 1-8, L, R, PFL
GL3000-M32 32way VU meterpod
GL3000-M40 40way VU meterpod
Optional
SYS-LINK buss expander system
GL3000-SL1 One kit required per console. User to source interconnecting cables.
THE RANGE
