ALLEN & HEATH iDR-48 - Fixed format iLive dimensions and weights

iLive Reference Guide – Hardware Part 1 - 41 AP6526-1 iss.5
Fixed format iLive dimensions and weights
280mm / 11"
620mm / 24.4"
635mm / 25"
46mm / 1.8"
1083mm / 42.6"
768mm / 30.2"
T80 WEIGHT = 20kg / 44lbs
T112 WEIGHT = 27kg / 59.4lbs
T112 SURFACE
T80 SURFACE
iDR-32
iDR-48
iDR-64
iDR-16
132mm / 5.2"
265mm / 10.4"
353mm / 13.9"
399mm / 15.7"
482mm / 19"
iDR-32 WEIGHT = 11.5kg / 25.3lbs
iDR-16 WEIGHT = 7.5kg / 16.5lbs
iDR-48 WEIGHT = 14.5kg / 31.9lbs
iDR-64 WEIGHT = 17.5kg / 38.5lbs
3U
6U
8U
9U
250mm / 9.9"
250mm / 9.9"
250mm / 9.9"
300mm / 11.8"
DEPTH
DEPTH
DEPTH
DEPTH
MIXRACKS
