36 ML5000 Service Manual
IDC connector harnesses:
DESCRIPTION
ORDER CODE
10 way GRAUX harness AL4029
10 way Input harness AL4028
10 way LRC to Fader harness AL4077
10 way MIDI harness AL4032
16 way GRAUX harness AL4030
20 way Master Connector harness AL4027
20 way Meter harness AL4021
26 way CPU Power harness AL4033
26 way LRC Connector harness AL4031
26 way Distribution harness AL4020
26 way Slave A harness AL4022
26 way Slave B harness AL4023
26 way Slave C harness AL4024
26 way Slave D harness AL4025
34 way Master harness AL4026
Sidecar harness AL4067
ML5-32 Left harness AL3964
ML5-32/40 Right harness AL3967
ML5-40/48 Left harness AL3834
ML5-48 Right harness AL3835
THE CHASSIS TRIM
DESCRIPTION
ORDER CODE
ML5000 (all formats) Left & Right Chassis side trims AA3773-L/R
Left & Right Moulded side trims AA3781-L/R
Write-on strip 10’ AK0327
Ident strip Master Rear AK3788
Ident strip Master AK3833
Ident strip 1-24 AK3789
Ident strip 1-24 Rear AK3790
Ident strip 25-48 AK3795
Ident strip 25-48 Rear AK3796
