40 ML5000 Service Manual
ORDERING AN MPS14 SPARES KIT
It is recommended that the spares kit order code 002-632 is held and maintained by the service agent
to enable in-field service repairs to the MPS14 independent of the ALLEN & HEATH factory.
Commonly available items such as resistors, capacitors, tools and soldering equipment are not
included. The contents of the kit are listed below and are supplied in a cabinet of drawers. Individual
spare parts may be ordered. Please quote the description and order code for the part required.
Power supply:
DESCRIPTION ORDER CODE QTY
Insulating Kit TO220 AA3514 5
Insulating Pad TDA7294 IC AA3645 4
Screw M3x 6mm Pan Pozi Black AB0072 10
Screw M3 x 8mm Pan Pozi Black AB0073 3
Screw M3 x 10 Pan Pozi Black AB0076 10
Nylock Nut M3 AB0102 5
Pillar M4 x 10 Nylon Tap AB0257 3
Screw M4 x 5 Pan Slotted Zinc AB0261 10
Screw M4 x 8 Countersunk Pozi Black AB2777 5
Screw 6B x 5/16 Pan Pozi Black AB2809 10
Screw 4 x 5/16 Poly Pan Pozi Black AB2810 10
Clip TO220 Type 4426 AB3547 3
Clip TO247 Type MAX03 AB4069 3
Clip TO220 Type MAX10 AB4099 3
Clip TO247 Type 4597 AB4148 3
Res W/Wound 0R33 2.5W 5% AC3014 3
Preset 1K Carbon Vertical Adjust AC3958 1
Res Planar 10R 10W AC4002 2
Zener Diode BZX85 5V6 1.3W AE0012 3
IC TL072 Dual Op-Amp AE0046 3
IC 7815 Regulator AE0047 2
Transistor BC637 NPN TO92H AE0068 2
IC LM339N Quad Comparator AE0071 3
IC Adjustable Regulator 783 AE0214 2
IC Op-Amp NE5532N AE0221 3
Zener Diode BZX55C2V7 AE0231 2
Zener Diode BZX79C 12V 400mW AE0232 2
IC Regulator 7818 AE3155 2
Diode BYW81P-200 15A AE3468 2
Diode BYV27-400 2A AE3469 3
Diode BYV26E 1A 1000V AE3470 3
Diode P6KE200A AE3471 3
Transistor Mosfet STP4NA80FP AE3472 3
