ALLEN & HEATH ML5000 Service Manual

34 ML5000 Service Manual
ORDERING A CONSOLE
To order a new console please specify the model number and AC mains voltage for the Power Supply.
MODEL DESCRIPTION ORDER CODE
ML5000-32
32 Mono + 4 Stereo Input Channels ML5000-32
ML5000-40
40 Mono + 4 Stereo Input Channels ML5000-40
ML5000-48
48 Mono + 4 Stereo Input Channels ML5000-48
MPS14
Power Supply for ML5000 MPS14/*
* - Specify the voltage and mains plug requirement for your area.
ORDERING AN ACCESSORY
To order an option please specify the model number required.
MODEL DESCRIPTION ORDER CODE
SIDECAR EXPANDER
OPTIONAL 24 MONO INPUT SIDECAR ML5000-24SC
DC POWER LEAD
2.9 METRE DC POWER LEAD 002-583
DC COMBINER LEAD
0.75 METRE DC COMBINER LEAD 002-584
SYS-LINK CABLE
2.8 METRE 37 WAY AUDIO CABLE 002-617
LOGIC CABLE
2.9 METRE 9 WAY LOGIC CABLE AL4155
GOOSENECK LAMP
18” GOOSENECK LAMP AL4061
32 CHANNEL DUSTCOVER
32 CHANNEL VINYL DUSTCOVER AP4121
40 CHANNEL DUSTCOVER
40 CHANNEL VINYL DUSTCOVER AP4122
48 CHANNEL DUSTCOVER
48 CHANNEL VINYL DUSTCOVER AP4123
SIDE-CAR DUSTCOVER
SIDECAR VINYL DUSTCOVER AP4234
MANUALS AND SUPPORT DOCUMENTATION
MODEL DESCRIPTION ORDER CODE
ML5000
User Guide AP3736
ML5000 SIDECAR
User Guide AP4124
MPS14 POWER SUPPLY
User Guide AP3898
SERVICE TOOLS
The tools required to service the ML5000 are standard to an electronics service workshop and are
easily obtainable. The following items are necessary for disassembly and service access:
TOOL USE ORDER CODE
4mm Hexagon (Allen) key M6 side trim AT0033
1-point Crosshead screwdriver M3, 4AB AT0004
2-point Crosshead screwdriver M4, 6AB, 8B AT0002
11mm AF Nutdriver Potentiometer and headphone nuts
12mm Nutdriver Jack nuts
1.27mm Hexagon (Allen) key PSU DC Leads AT4142
2.5MM hexagon (Allen) key M4 Sidetrim
5.5mm AF Spanner Fader PCB M3 Hex
5mm Nutspinner D-Type Screws
