ALLEN & HEATH ML5000 Service Manual

ML5000 Service Manual 35
ORDERING AN ASSEMBLY
The following assemblies for the ML5000 are supplied fully tested. Please quote the description and
order code for the part required.
Printed circuit board (PCB) assemblies:
DESCRIPTION ORDER CODE
Mono Input PCB assembly 002-529
Stereo Input PCB assembly 002-564
Group 1, 3, 5, 7 PCB assembly 002-552
Group PCB assembly 002-553
Group 2, 4, 6, 8 PCB assembly 002-554
Aux 10 PCB assembly 002-545
Aux 12 PCB assembly 002-546
Aux 14 PCB assembly 002-547
Aux 16 PCB assembly 002-548
Master Distribution PCB assembly 002-556
LCR Mix PCB assembly 002-544
Mono Fader PCB assembly 002-530
Master Fader Centre PCB assembly 002-589
Master Fader L/R PCB assembly 002-588
Master Fader VCA PCB assembly 002-557
Mute Group PCB assembly 002-563
Control Panel PCB assembly 002-549
Fader Slave PCB assembly 002-551
Stereo Slave PCB assembly 002-566
VCA Master Slave PCB assembly 002-567
Aux Master Slave PCB assembly 002-543
CPU PCB assembly 002-550
Mono Connector PCB assembly 002-560
Stereo LRC Connector PCB assembly 002-565
Master Connector PCB assembly 002-555
MIDI Power PCB assembly 002-575
Sidecar MIDI Power PCB assembly 002-598
SYS-LINK 2 In PCB assembly 002-587
SYS-LINK 2 Out PCB assembly 002-596
Meter 1-8 PCB assembly 002-558
Meter 9-16 PCB assembly 002-591
Meter Master PCB assembly 002-559
Meter Ledbar PCB assembly 002-590
