ALLEN&HEATH iLive Reference Guide AP6526 iss.3 45
Gated Verb
‘Gated Verb’ hosts the classic 80’s emulation plus ‘panned’ and ‘powerbox’
gated reverb presets. The user interface gives instant access to lo-cut hi-cut
decay spectrum filters and the gate envelope controls. We depart from the
80’s and provide a visual representation of the gate time domain envelope
helping the engineer ‘see’ the sound effect. Also included are mono, stereo
and wide imaging options and decay diffusion.
Classic Nonlinear - emulates the faithful 80’s classic gated reverb. Even left
and right distribution with de-correlated and diffuse reverb.
Panner - rapid panning between Left/Right in the reverb, creates short time
movement effects.
Powerbox - maximum power in gated energy, not as de-correlated as classic
non-linear.
Lo Cut 20Hz - 6 KHz, 24dB/octave filter to control decay spectrum
Hi Cut 400Hz – 20KHz, 12dB/octave filter to control decay spectrum
0 - 170ms adjustable pre-delay prior to attack starting
Attack, Hold, Release Time period for gate to open, remain open, and close
Maximum open gate length (attack + hold + release) = 500ms.
Mono/Stereo/Wide - option to set field output image.
Diffusion - from ‘clear’ (low diffusion) to ‘rich’ (highly diffused)
Empty rack
Recalling the ‘Empty Rack’ from the Library removes the current FX type
loaded. The screen displays a space as if a unit had been removed from a
traditional outboard rack. Recall a library preset to load in another FX device.
Gate Echo
Gate RevPan
Gate Short
Gated Big Pan
Gated Drum Big
Gated Drums Sml
Gated Kick
Gated Rev
Gated Snare
Gated Vocal
